MAGNETIC FLUOR BALLAST F48T12/HO 120V PHILIPS 506972
MFR Part #: RC4S60TPI
SKU #: 1117269
Brand: Signify | Advance
UPC: 781087397626
Advance RC4S60TPI Standard Electromagnetic Fluorescent Ballast, 85 W, 120 VAC, Rapid, 0.92 Ballast Factor
This product may be subject to ecological fees.
TV or Radio Station, Library, Reception or Reading Room, Church and School Study Hall
UL File No. E14927 | CSA File No. 007310 | ANSI C82.1 | RoHS Compliant
Product Details
Attributes
Features
Resources
Advance Electromagnetic Fluorescent Ballast, Series: Standard, 85 W Lamp, 120 VAC, 2.4 A, 60 Hz, Rapid Start, -20 deg F Minimum Starting, Total Harmonic Distortion: 0.3, Power Factor: 0.98, 4 Lamps, Thermal Protection: Class P, Ballast Factor: 0.92, Metal, 11.75 in L x 3.19 in W x 2.63 in H
Amperage Rating:2.4 A
Ballast Factor:.92
Dimensions:11.75 in L x 3.19 in W x 2.63 in H
Frequency Rating:60 Hz
Lamp Wattage:85 W
Material:Metal
Minimum Starting Temperature:-20 deg F
Number of Lamps:4
Power Factor:.98
Series:Standard
Start Type:Rapid
Thermal Protection:Class P
Total Harmonic Distortion:.3
Voltage Rating:120 V AC
- Series lamp connection
- 112 - 127 VAC Applied voltage limits
- Yellow color label identification
- 31 - 36 dB Average ambient noise level
- Normal power factor
- Available for many fluorescent lamp types sold today, including Preheat, Rapid Start, 2-pin CFL, Slimline, High Output, Very High Output and Circline
- Only choice for many low volume lamp types on the market
- 60 Hz lamp operation eliminates possible EMI/RFI interference
- Class B Insulation
Product Details
Advance Electromagnetic Fluorescent Ballast, Series: Standard, 85 W Lamp, 120 VAC, 2.4 A, 60 Hz, Rapid Start, -20 deg F Minimum Starting, Total Harmonic Distortion: 0.3, Power Factor: 0.98, 4 Lamps, Thermal Protection: Class P, Ballast Factor: 0.92, Metal, 11.75 in L x 3.19 in W x 2.63 in H
Attributes
Amperage Rating: 2.4 A
Ballast Factor: .92
Dimensions: 11.75 in L x 3.19 in W x 2.63 in H
Frequency Rating: 60 Hz
Lamp Wattage: 85 W
Material: Metal
Minimum Starting Temperature: -20 deg F
Number of Lamps: 4
Power Factor: .98
Series: Standard
Start Type: Rapid
Thermal Protection: Class P
Total Harmonic Distortion: .3
Voltage Rating: 120 V AC
Features
- Series lamp connection
- 112 - 127 VAC Applied voltage limits
- Yellow color label identification
- 31 - 36 dB Average ambient noise level
- Normal power factor
- Available for many fluorescent lamp types sold today, including Preheat, Rapid Start, 2-pin CFL, Slimline, High Output, Very High Output and Circline
- Only choice for many low volume lamp types on the market
- 60 Hz lamp operation eliminates possible EMI/RFI interference
- Class B Insulation
