EATON FAZ-C15/1-NA-SP Image 1

EATON FAZ-C15/1-NA-SP 15A 1-POLE DEFINITE PURPOSE CONTACTOR BOX LUGS

MFR Part #: FAZ-C15/1-NA-SP
SKU #: 1309971
Brand: EATON
UPC: 4015081636341
EATON FAZ-C15/1-NA-SP Miniature Circuit Breaker, 277/480 V AC, 15 A, 10 to 15 kA Interrupt, 1 Poles, Thermal Magnetic Trip
PLC I/O Points, Computers, Power Supplies, Control Instrumentation, Relays, UPS, Power Conditioners and Circuit Protection Applications
CSA Std. C22.2 No. 235,UL 489

EATON Miniature Circuit Breaker, 277/480 V AC, 15 A, 50 to 60 Hz Frequency, 10 to 15 kA Interrupt, Thermal Magnetic Trip, 5 to 10X In Trip, 1 Pole, Toggle Actuator, Screw Connection, IP20 Enclosure, DIN Rail Mounting, -25 to 75 deg C, 0.7 in L x 2.97 in W x 4.13 in H Dimensions

Eaton's FAZ, dual rated UL and IEC circuit breakers are ideal for providing protection in many applications. A current limiting design provides fast short-circuit interruption, offering superior protection by reducing peak let-through current. Superior product quality, tested reliability and safety make Eaton’s UL 1053 Residual Current Circuit Breaker (RCCB) the optimum product for residual current applications. The UL 1053 RCCB circuit breakers provide safety and protection for personnel and equipment.

Product Details

EATON Miniature Circuit Breaker, 277/480 V AC, 15 A, 50 to 60 Hz Frequency, 10 to 15 kA Interrupt, Thermal Magnetic Trip, 5 to 10X In Trip, 1 Pole, Toggle Actuator, Screw Connection, IP20 Enclosure, DIN Rail Mounting, -25 to 75 deg C, 0.7 in L x 2.97 in W x 4.13 in H Dimensions

Eaton's FAZ, dual rated UL and IEC circuit breakers are ideal for providing protection in many applications. A current limiting design provides fast short-circuit interruption, offering superior protection by reducing peak let-through current. Superior product quality, tested reliability and safety make Eaton’s UL 1053 Residual Current Circuit Breaker (RCCB) the optimum product for residual current applications. The UL 1053 RCCB circuit breakers provide safety and protection for personnel and equipment.

Attributes

Actuator Type: Toggle
Amperage Rating: 15 A
Connection Type: Screw
Dimensions: 0.7 in L x 2.97 in W x 4.13 in H
Enclosure Type: IP20
Frequency Rating: 50 to 60 Hz
Mounting Type: DIN Rail
Number of Poles: 1
Trip Type: Thermal Magnetic

Features

  • Current limiting design provides fast short circuit interruption that reduces the let through energy, which can damage the circuit
  • Suitable for branch circuit device protection
  • Thermal magnetic overcurrent protection
  • Trip free design breaker can not be defeated by holding the handle in the ON position
  • Captive screws cannot be lost
  • Field installable shunt trip and auxiliary switch subsequent mounting
  • Easy installation on DIN rail
  • Possibility for sealing the toggle in ON or OFF position
