Grundfos VersaFlo® Circulator Pump, Series: UPS, 130 gpm, 78.74 ft Maximum Head, 1350 W, 230 V AC, 5.15 to 6.2 A, 60 Hz, 1 ph, 145 psi Maximum, 3196 to 3412 rpm Motor, 32 to 104 deg F Ambient, X4D, 13-3/8 in W x 13-1/2 in H
The pump is of the canned rotor type, i.e. pump and motor form an integral unit without shaft seal and with only two gaskets for sealing. The bearings are lubricated by the pumped liquid. In order to avoid problems in connection with disposal, great importance has been attached to using as few different materials as possible.
- 3-speed motor
- Ceramic radial bearings
- Carbon axial bearing
- Stainless steel rotor can, bearing plate and rotor cladding
- Aluminum alloy stator housing
- Cast iron pump housing
- Stator with built-in thermal switch
